CCTV Distributed Power Box-DH-PFM341-9CH

Model

DH-PFM341-9CH

Input Voltage Range

AC 90~264V

Outputs

9 x 12VDC (-3%~+7%) outputs

Max. Output

5 A

Output Protection

9 replacement fuses, max. per output 2.5A

Efficiency

84%

No Load Power Consumption

<0.5W

Internal ON/OFF Power Switch

Yes

Individual LED Output Indicator

Yes

Surge Protection

Line to ground: 4000VLine to line: 2000V

ESD

Contact discharge: 6000VAir discharge: 8000V

Working Temperature

-20°C~+45°C (-4°F~+113°F)

Working Humidity

<90% RH

Physical Properties

Weight: 0.9kg (1.98lb)

Dimension (LxWxH)

165mm x 165mm x 50mm (6.5” x 6.5” x 1.97”)

Installation

Wall mount

Color

White

Safety Standards

Certification: CE (EN55032, EN55020)FCC (FCC Part 15 Class B, ISED ICES-003 Issue 6)
