Category: Consumer Electronics
Subcategory: CCTV, Surveillance Systems and Parts
Brand: Dahua Accessories
Sold by: Tejas Enterprises Pvt. Ltd.
Minimum Order Quantity: 1 PCS
Transmission Signal
1 channel
Transmission Distance
HDCVI:- 720P: max. 400m (1312.34 ft)- 1080P: max. 250m (820.21 ft)
Video Connectors
- Coaxial: BNC-M- Twisted-pair: Push-terminal
Compatible Formats
HDCVI, AHD, TVI, CVBS
Supported Resolutions
720P, 1080P
Anti-interference
≥60 dB
ESD Protection
- Contact discharge: Level 3- Air discharge: Level 3 (IEC61000-4-2)
Coaxial Cable Connector
2 kV (common-mode) (IEC1000-4-5)
UTP Cable Connector
- 2 kV (differential-mode)- 4 kV (common-mode) (IEC1000-4-5)
Impedance
- BNC Male: 75 ohms,- UTP Cable: 100 ohms
Dimensions (L x W x H)
180 mm x 19 mm x 16 mm (7.09" x 0.75" x 0.63")
Housing Material
ABS
Color
Black
Net Weight
42 g/pair (0.09 lb)
MTBF
≥10,000 hours
Operating Temperature
-10°C to +55°C (14°F to 131°F)
Storage Temperature
-20°C to +70°C (-4°F to 158°F)
Humidity
0% to 95% (non-condensing)
Seller Information
Tejas Enterprises Pvt. Ltd.
Importer, Exporter, Wholesaler/Dealer/Distributor
The PFM800-E is a 1-channel passive HDCVI balun that enables real-time video transmission over UTP CAT5E/6 cables without the need for a power supply. Featuring a female BNC connector and pluggable screw terminal connections, this compact and versatile device simplifies the integration of HDCVI cameras into surveillance systems. Capable of supporting resolutions up to 1080P, the PFM800-E ensures reliable and high-quality video transmission with a maximum distance of 400m for 720P and 250m for 1080P. Designed for ease of use and installation, this passive balun requires no additional power, making it an efficient and cost-effective solution for extending HDCVI video signals over long distances using standard Ethernet cabling.
