Dahua - DHL550UDM-EG 55’’ FHD Video Wall Display Unit (Ultra Narrow Bezel 1.8mm)


Minimum Order Quantity: 1 PCS


Diagonal

55" (16:9)

LCD Technology

IPS

Resolution

1920×1080 (FHD)

Bezel Width

0.9mm (U/L/R/B)

Backlight

Direct LED

Brightness/Luminance

500 cd/m²

Contrast Ratio

1400:1

Pixel Density

40 dpi

Viewing Angle

H178°, V178°

Response Time

8ms

Display Color

10 bit (1.07B)

Color Temperature

10,000K

MTBF

50,000h

Input

CVBS (BNC) ×2, VGA (D-Sub) ×1, DVI-D ×1, HDMI ×1, RS232 ×1, USB ×1, IR ×1

Output

CVBS (BNC) ×2, RS232 ×1

Power Supply

AC 100V ~ AC 240V, 50/60 Hz

Power Consumption (Standby)

≤0.5W

Power Consumption (Typical)

100W

Power Consumption (Max.)

160W

Installation Mode

Floor-standing, wall-mounted

Control Mode

Infrared, RS232 dual mode, supporting remote PC control

Net Weight

24kg (52.91 lb)

Gross Weight

31kg (68.34 lb)

Dimension (W×H×D)

1211.5mm × 682.4mm × 117.5mm (47.7" × 26.9" × 4.6")

Package (W×H×D)

1360mm × 945mm × 280mm (53.5" × 37.2" × 11.0")

Temperature

0°C ~ +50°C

Humidity

10% RH ~ 90% RH


T

Seller Information
Tejas Enterprises Pvt. Ltd.

Importer, Exporter, Wholesaler/Dealer/Distributor

verified image
Verified Supplier

Assured Image

Product Display :

Industrial level IPS LCD panel, suitable for extensive 24/7 continuous works
> Ultra-narrow 1.8mm bezel-to bezel design(0.9mm even panel bezel)
> High contrast ratio and high brightness greatly enhance the video layering, and present the details of the video
> High fidelity digital processing, brilliant and vivid video
> Built-in 3D COMB filter and 3D Noise Reduction
> Abundant interfaces HDMI, DVI, VGA, BNC, USB, support video loop
> Built-in picture splicing function
> Infrared, RS232 dual mode, supporting remote PC control
> Professional thermal design to extend equipment lifespan
> Built-in power, low energy consumption, ultra-quiet
> Fast stack installation, professional project design, supporting arc-shaped mounting
> Widely used in surveillance center, command center, meeting room, commercial display scenes, etc.
