Dahua Channel IP Mobile DVR-DHI-MNVR1104: 4

Available

Category: Consumer Electronics

Subcategory: Mobile Phone & Accessories

Brand: Dahua Mobile

Sold by: Tejas Enterprises Pvt. Ltd.

Minimum Order Quantity: 1 PCS

Video Inputs

4 pcs Ethernet + PoE (802.3af/at) - M12, 4-pin plug

Video Outputs

1 pcs CVBS, 1 pcs VGA - M16, 10-pin socket

Audio Inputs

4 pcs - Audio from cameras, External microphone - 2-pin

Audio Outputs

1 pcs - 2-pin

Resolution of Recording Video Files

1920 x 1080, 1280 x 720, 720 x 576, 352 x 576

Maximal Total Frame Rate

100 fps @ 4 x IP 1080p

Bitrate

100 Mbps

Network Protocols

TCP/IP, UDP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, E-mail, Alarm Server, ONVIF 2.3

Supported Hard Drives

1 pcs 2.5" - 2 TB SATA

Max. Capacity of Memory Card

128 GB SD/SDHC

Image Compression Method

H.264

Number of Compression Levels

GPS

Not specified

G-Sensor

Not specified

SIM Socket

Not specified

RS-485

PELCO-D/P

RS-232

Not specified

Alarm Inputs / Outputs

7 / 2

Power Supply

6 V ... 36 V DC

Power Consumption

≤ 15 W (without HDD)

Operation Temp

-30 °C ... 60 °C

Permissible Relative Humidity

10 % ... 95 % RH

Weight

2.05 kg

Dimensions

180 x 230 x 50 mm

Manufacturer / Brand

DAHUA

Seller Information
Tejas Enterprises Pvt. Ltd.

Importer, Exporter, Wholesaler/Dealer/Distributor

Verified Supplier

The Dahua DHI-MNVR1104 is a robust 4-channel IP Mobile DVR designed for high-quality video surveillance in mobile environments. This device supports up to 4 Ethernet channels with PoE, making it easy to power and connect IP cameras. The video outputs include 1 CVBS and 1 VGA port, allowing for versatile display options. With support for 1080p resolution recording at up to 100 fps, the DVR ensures clear and detailed footage. It features H.264 video compression, 7 alarm inputs, 2 alarm outputs, and supports a 2.5" SATA HDD up to 2TB and an SD card up to 128GB. The unit operates efficiently within a wide temperature range and offers extensive network protocol support, ensuring reliable performance in various conditions.
