SSD-S820N512G-G1YTTANN8

Product Model

DHI-SSD-S820N512G / DHI-SSD-S820N1TB

Capacity

512 GB / 1 TB

Form Factor

SATA M.2 2280

Port

SATAIII 6Gb/s

Net Weight

Max. 8 g (0.02 lb)

Product Dimensions

80.00 mm × 22.00 mm × 2.20 mm

Packaging Dimensions

614 mm × 454 mm × 300 mm

Memory Component

3D NAND

Power Consumption

2000 mW (max), 500 mW (idle)

S.M.A.R.T

Yes

TRIM

Yes

Garbage Collection

Yes

Sequential Read

Up to 550 MB/s / Up to 490 MB/s

Sequential Write

Up to 460 MB/s

4K Random Read

Up to 45,000 IOPS / Up to 41,000 IOPS

4K Random Write

Up to 82,000 IOPS

MTBF

1,500,000 hours

Operating Temperature

0°C to +70°C (+32°F to +158°F)

Storage Temperature

-40°C to +85°C (-40°F to +185°F)

Operating Humidity

5%–95% (non-condensing)

Vibration Resistance

10-1000Hz, 2.78G

TBW

1000 TB / 2000 TB
