SSD-E800S512G

Product Model

DHI-SSD-E800S128G

Capacity

128 GB

Form Factor

2.5"

Port

6 Gb/s SATA

Net Weight

Max 40 g (0.09 lb)

Product Dimensions

100.20 mm × 69.90 mm × 7.00 mm (3.94" × 2.75" × 0.28")

Packaging Dimensions

140.50 mm × 105.50 mm × 15.50 mm (5.53" × 4.15" × 0.61")

Memory Component

3D TLC

Power Consumption

1065 mW (max), 400 mW (idle)

S.M.A.R.T

Support

TRIM

Support

Garbage Collection

Support

Sequential Read

Up to 550 MB/s

Sequential Write

Up to 410 MB/s

4K Random Read

Up to 37,000 IOPS

4K Random Write

Up to 57,000 IOPS

MTBF

1,500,000 hours

Operating Temperature

0°C to 70°C (32°F to 158°F)

Storage Temperature

–40°C to +85°C (–40°F to 185°F)

Operating Humidity

5%–95% (non-condensing)

Vibration Resistance

10–1000 Hz, 2.78G

Shock Resistance

1500G/0.5 ms (half sine wave)

TBW

60 TB

Warranty

3-year limited warranty
