Dahua-EVS5016S-R-V2-16-bay Embedded Video Storage

Processor

64-bit high-performance multi-core processor

OS

Embedded Linux OS

Cache

8 GB (extendable to 32 GB)

AI Applications

Face detection, recognition, IVS, video metadata, vehicle recognition, people counting, smart thermal, etc.

Camera Compatibility

Thermal, People Counting, Bullet-PTZ Smart Track, Fisheye Dewarp

Compression Standards

Smart H.265+, H.265, Smart H.264+, H.264, MJPEG

Network Protocols

HTTP, HTTPS, TCP/IP, IPv4, RTSP, UDP, SMTP, NTP, DHCP, DNS, DDNS, P2P, iSCSI, FTP, SMB, NFS

Third-party Camera Access

Onvif, RTSP, Sony, Panasonic, Axis, Arecont, Pelco, Canon, Samsung, Hikvision

Recording Playback

Max. 16-channel playback, Auto/manual record, search, intelligent event

Storage

Internal HDD, network disk, supports RAID, disk group, IPSAN

Ports

16 SATA HDD slots, eSATA, RS-232, 2 USB 3.0, HDMI, VGA, 2 RJ-45 ports

Power Supply

100-240 VAC, 50-60 Hz, 6.3A-3.5A

Dimensions

Chassis: 484.6 mm × 133.2 mm × 473.6 mm

Operating Conditions

0 °C to 45 °C, 10%–80% RH, 5000 m altitude

Certifications

CE, FCC

Network Ports Extension

4 × 1-GbE LAN ports (optional), 2 × 10-GbE optical fiber ports (optional)
