2MP Lite Full-Color Fixed-focal Eyeball Network Camera-IPC-HDW1239T1P-LED-S5


Minimum Order Quantity: 1 PCS


Image Sensor

1/2.7” 2 Megapixel progressive CMOS

Effective Pixels

1920 (H) × 1080 (V)

RAM/ROM

64 MB / 16 MB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual, 1/3s–1/100000s

Min. Illumination

0.005 Lux @ F1.6

IR LED Distance

2.8 mm: 10 m (32.8 ft); 3.6 mm: 15 m (49.2 ft)

IR LEDs

1

Lens Type

Fixed-focal

Lens Mount Type

M12

Focal Length

2.8 mm; 3.6 mm

Max. Aperture

F1.6

Field of View

2.8 mm: H 110°, V 59°, D 132°; 3.6 mm: H 91°, V 48°, D 109°

DORI Distance

2.8 mm: Detect 37.3 m, Observe 14.9 m, Recognize 7.5 m, Identify 3.7 m

Video Compression

H.265; H.264; MJPEG

Smart Codec

Yes

Video Resolution

1080P, 1.3MP, 720p, D1, VGA, CIF

Bit Rate Control

CBR/VBR

Day/Night

Color/B&W

WDR

DWDR

White Balance

Auto/natural/street lamp/outdoor/manual/regional custom

Power Supply

12V DC/PoE (802.3af)

Power Consumption

<4.8 W

Ingress Protection

IP67

Operating Temperature

-40°C to +60°C (-40°F to +140°F)

Dimensions

85.5 mm × Ø109 mm (3.4" × Ø4.3")

Weight

0.24 kg (0.5 lb)


T

Seller Information
Tejas Enterprises Pvt. Ltd.

Importer, Exporter, Wholesaler/Dealer/Distributor

verified image
Verified Supplier

Assured Image

The IPC-HDW1239T1P-LED-S5 is a 2MP Lite full-color fixed-focal eyeball network camera designed for robust surveillance applications. It features a 1/2.8" 2 Megapixel progressive CMOS image sensor with a maximum resolution of 1920 (H) × 1080 (V). With an electronic shutter speed of Auto/Manual, 1/3 s–1/100000 s, and a minimum illumination of 0.005 Lux @F1.6, it ensures clear imaging in various lighting conditions. The camera offers Smart IR LED technology for up to 30 meters (98.4 ft) of night vision and supports H.265/H.264 compression for efficient video encoding. It's housed in a durable IP67-rated casing for outdoor use.
