4MP Entry IR Vari-focal Bullet Network Camera-IPC-HFW1431T1P-ZS-S4

W

66.0 m (183.7 ft)

T

200.0 m (656.2 ft)

Image Sensor

1/3” 4MP progressive CMOS

Effective Pixels

2688 (H) × 1520 (V)

RAM/ROM

128MB / 128MB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual, 1/3~1/100000s

Minimum Illumination

0.03 Lux @ F1.7

S/N Ratio

> 56dB

IR Distance

50m (164.04 ft) (IR)

IR On/Off Control

Auto/Manual

IR LEDs

2

Lens

Motorized vari-focal

Mount Type

?14

Focal Length

2.8mm – 12mm

Max. Aperture

F1.7

Angle of View

Horizontal: 98°–31° Vertical: 55°–18° Diagonal: 116°–36°

Focus Control

Fixed

Close Focus Distance

0.8m (2.6 ft)

DORI Distance

Lens

PTZ

Pan: 0° ~360° Tilt: 0° ~90° Rotation: 0° ~360°

Intelligence

Motion detection, Video tampering, Scene changing, Network disconnection, IP address conflict, Illegal access, Storage anomaly

IVS

NA

Video Compression

H.265; H.264; H.264B; MJPEG (Only supported by the sub stream)

Smart Codec

Smart H.265+; Smart H.264+

Streaming Capability

2 Streams

Resolution

2688 × 1520; 2560 × 1440; 2304 × 1296; 1080p; 1.3M; 720p; D1; VGA; CIF

Frame Rate

Main Stream: 2688 × 1520 (1 fps–20 fps) 2560 × 1440 (1 fps–25/30 fps) Sub Stream: 704 × 576 (1 fps–20/25 fps) 704 × 480 (1 fps–20/30 fps)

Bit Rate Control

CBR/VBR

Bit Rate

H.264: 32 kbps–6144 kbps H.265: 12 kbps–6144 kbps
