CA095-R3-PSE Camera Power Adapter (12V 1A)

Image Sensor

1/2.8" CMOS

Effective Pixels

1920(H)×1080(V), 2MP

Scanning System

Progressive

Electronic Shutter Speed

PAL: 1/251/100000s, NTSC: 1/301/100000s

Minimum Illumination

0.01Lux/F1.6, 0Lux with white light on

S/N Ratio

More than 65dB

IR Distance

Up to 20 m (65.61 ft)

IR On/Off Control

Auto / Manual

IR LEDs

1

Lens Type

Fixed lens / Fixed iris

Mount Type

M12

Focal Length

3.6mm (2.8mm Optional)

Max Aperture

F1.6

Angle of View

2.8 mm: 126.2° (Diagonal), 106° (Horizontal), 56.5° (Vertical)

Focus Control

N/A

Close Focus Distance

2.8 mm: 0.6 m (1.97 ft), 3.6 mm: 1.2 m (3.94 ft)

DORI Distance (Detect)

2.8mm: 38.6 m (126.6 ft), 3.6mm: 55.2 m (181.1 ft)

DORI Distance (Observe)

2.8mm: 15.4 m (50.5 ft), 3.6mm: 22.1 m (72.5 ft)

DORI Distance (Recognize)

2.8mm: 7.7 m (26.3 ft), 3.6mm: 11.0 m (36.1 ft)

DORI Distance (Identify)

2.8mm: 3.9 m (12.8 ft), 3.6mm: 5.5 m (18.0 ft)
