Category: Scientific, Measuring, Laboratory Instruments & Supplies
Subcategory: Metallurgical & Lab Microscopes
Brand: Not Mentioned
Sold by: Easy Tools
Minimum Order Quantity: 10 PCS
Observation Head
45° decline, 360° rotation, pupil distance 54–76mm, bilateral visual adjustment ±5
Adjustable Eyepiece
Standard: WF10X22; Optional: WF10x22mm, WF15x15mm, WF20x10mm, WF25x9mm, WF30x8mm
Objective
0.6X–4.5X Zoom Range, objective magnification ratio 1:10
Auxiliary Lens
Options: 0.3X, 0.5X, 0.75X, 1X, 1.5X, 2X
Magnification
Standard: 6X–45X; Extendable to 1.8X–90X with optional and auxiliary lenses
Working Distance
100mm
Focus Arm
76mm Diameter, 32mm pole size
Plate
Black/White
Base
B11 column type large plate base, other options available
Outward Size
200mm(W) × 273mm(D) × 280mm(H)
Illumination
Optional LED Illumination (refer to LED light source series diagram for details)
Introducing our advanced microscope: Precision-engineered with a high-definition optical objective lens and pure copper lens barrel, it ensures unparalleled clarity. Featuring WF10X/22MM eyepieces and adjustable diopter, observation is comfortable and precise. Its 0.6-4.5X continuous zoom delivers sharp, distortion-free imaging, ideal for intricate samples. With a durable metal focusing gear rack and CTV2/5 adapter, clarity and wide field of view are guaranteed. Synced with a 4K camera, the true trinocular display offers crystal-clear visuals on a large screen. Flexible adjustments and a 360° rotatable body optimize workspace efficiency. Elevate your observations with precision and clarity in every detail.
