Hinge Boring Model No.J-31(V)

Model Number

J-31 (V)

Max. Working Thickness

70 mm

No. of Spindles per Head

3

No. of Spindle Head

One

Shank Diameter of Drill

10 mm

Drilling Depth

0 - 50 mm (Drill Length: 70 mm)

Air Pressure Required

6 to 7 kg/cm²

Electric Motor / Total Power

1 x 1.5 hp = 1.5 hp

Machine Dimensions (L x B x H)

1020 mm x 700 mm x 1500 mm

Approx. Net Weight

100 kg
